PAX A77

The A77, from PAX, is a mobile phone-size Android terminal with a 5.5” color touchscreen, an integrated professional scanner, dual high-resolution cameras, and a long-lasting battery. It accepts all payment types and is perfect for Pay-at-Table or retail settings. The A77 connects via Ethernet or Bluetooth.

The A77 is available from select distributors today that is EMV-ready.

Here’s what you’ll need to order:

  1. Pax A77 (A77-0AW-RD5-20EA)

  2. Included USB Cable

  3. Included Power Supply

  4. Datacap ECN (see chart below)

  5. Encryption Key (see chart below)

  6. Datacap Forms Package
    1.
Pax A77 Datacap

Download the Brochure

A77 brochure

Distribution Partners

The A77 can be ordered directly from the vendors below.

The A77 is US EMV certified with the following Processors and Datacap products today:

Via NETePay Hosted

NETePay

TranCloud

DC Direct

Chase Logo

Via NETePay Hosted

NETePay

DC Direct

Clearent Logo

Via NETePay Hosted

NETePay

TranCloud

DC Direct

Cygnus Payments

Via NETePay Hosted

NETePay

TranCloud

DC Direct

EMS

Via NETePay Hosted

NETePay

TranCloud

DC Direct

Electronic Payments

Via NETePay Hosted

NETePay

TranCloud

DC Direct

EVO

Via NETePay Hosted

NETePay

TranCloud

DC Direct

First Data

Via NETePay Hosted

NETePay

TranCloud

DC Direct

Heartland

Via NETePay Hosted

NETePay

TranCloud

DC Direct

IMS

Via NETePay Hosted

NETePay

TranCloud

DC Direct

Via NETePay Hosted

NETePay

TranCloud

DC Direct

Via NETePay Hosted

NETePay

TranCloud

DC Direct

Priority

Via NETePay Hosted

BOLD Integrated

Via NETePay Hosted

NETePay

TranCloud

DC Direct

Truist - BBT Logo

Via NETePay Hosted

NETePay

TranCloud

DC Direct

TSYS

Via NETePay Hosted

NETePay

TranCloud

DC Direct

Worldpay FIS logo

Via NETePay Hosted

NETePay

DC Direct

NETePay Hosted™ Secure Device IDs

Datacap ECN (Config)Encryption KeySecureDeviceID
Encrypted (recommended)Non-Encrypted
ECN232022Datacap TDES DUKPT - Slot 2EMV_A77_DATACAP_E2E
EMV_A77_DATACAP_BLUEFIN (PCI-Validated P2PE)
N/A
Datacap ECN (Config)Encryption KeySecureDeviceID
Encrypted (recommended)Non-Encrypted
ECN232022Datacap TDES DUKPT - Slot 2PAXA77_DATACAP_E2E
PAXA77_DATACAP_BLUEFIN (PCI-Validated P2PE)
N/A

*Includes Datacap’s NETePay™, NETePay Hosted™, TranCloud™ and Tran™ Series products.

Processor-Specific Secure Device IDs

ProcessorDatacap ECN (Config)Encryption KeySecureDeviceID
Encrypted (recommended)Non-Encrypted
Chase*ECN232022N/AN/AEMV_A77_PAYMENTECH
EVO SnapECN232022EVO TDES DUKPT - Slot 2EMV_A77_EVON/A
HeartlandECN232022Heartland VoltageEMV_A77_HEARTLANDN/A
Fiserv/RapidConnectECN232022TransArmor TDES DUKPT - Slot 2EMV_A77_RAPIDCONNECT_E2EEMV_A77_RAPIDCONNECT
TSYSECN232022TSYS VoltageEMV_A77_TSYS_VOLTEMV_A77_TSYS
FIS/Worldpay Core610ECN232022Worldpay (Core 610) TDES DUKPT - Slot 2EMV_A77_VANTIV_E2EN/A

ProcessorDatacap ECN (Config)Encryption KeySecureDeviceID
Encrypted (recommended)Non-Encrypted
ChaseECN232022N/AN/APAXA77
EVO SnapECN232022EVO TDES DUKPT - Slot 2PAXA77_EVO_E2EPAXA77
HeartlandECN232022Heartland VoltagePAXA77_HEARTLAND_VOLTPAXA77
Fiserv/RapidConnectECN232022TransArmor TDES DUKPT - Slot 2PAXA77_RAPIDCONNECT_E2EPAXA77
TSYSECN232022TSYS VoltagePAXA77_TSYS_VOLTPAXA77
FIS/Worldpay Core610ECN232022Worldpay (Core 610) TDES DUKPT - Slot 2PAXA77_VANTIV_E2EPAXA77

*Encryption available via NETePay Hosted
