Home / Compatible Devices / ID Tech MiniSmart II
The MiniSmart II, from ID Tech, is an EMV contact reader module for easy OEM Integration.
The ID Tech MiniSmart II is available from select distributors today that is EMV-ready.
Here’s what you’ll need to order:
MiniSmart II USB Molex (Part #’s vary per processor, see chart below)
SecureHead MSR (Part #’s vary per processor, see chart below)
Processor-Specific E2E Key (See chart below)
The MiniSmart II can be ordered directly from the vendors below.
*** For EVO, the MiniSmart II can only be sourced from Ingram Micro / TPG***
NETePay Hosted
NETePay
NETePay Hosted
NETePay
NETePay Hosted
NETePay
NETePay
NETePay Hosted
NETePay Hosted
NETePay
NETePay Hosted
NETePay
NETePay Hosted
NETePay
NETePay Hosted
NETePay
NETePay Hosted
NETePay
NETePay Hosted
NETePay
NETePay Hosted
NETePay
NETePay Hosted
NETePay
NETePay
NETePay Hosted
| MiniSmart II Chip Reader | SecureHead MSR Reader | Recommended Firmware | Processor E2E Key | SecureDeviceID | |
|---|---|---|---|---|---|
| Encrypted (recommended) | Non-Encrypted | ||||
| MINI2-50 | IDHA-5442 | V2.01.002 | IDT-KEYINJ-287 | EMV_MINISMART_DATACAP | N/A |
*Includes Datacap’s NETePay™, NETePay Hosted™, TranCloud™ and Tran™ Series products.
| Processor | MiniSmart II Chip Reader | SecureHead MSR Reader | Recommended Firmware | Processor E2E Key | SecureDeviceID | |
|---|---|---|---|---|---|---|
| Encrypted (recommended) | Non-Encrypted | |||||
| EVO Snap | MINI2-50 | IDHA-5442AE | V2.01.002 | IDT-KEYINJ-343 | EMV_MINISMART_EVO | N/A |
| First Data Rapid Connect | MINI2-50 | IDHA-5442AE | V2.01.002 | TransArmor E2E Key | EMV_MINISMART_RAPIDCONNECT_E2E | N/A |
| Heartland | MINI2-50 | IDHA-5442AE | V2.01.002 | C12012 | EMV_MINISMART_HEARTLAND | N/A |
| TSYS | MINI2-50 | IDHA-5442 | V2.01.002 | N/A | N/A | EMV_MINISMART_TSYS |
| Worldpay IP (Mercury) | MINI2-50-1M | IDHA-5442E-F2 | V2.01.002 | IDT-KEYINJ-058 | EMV_MINISMART_MERCURY | N/A |
